Automatic Sealing Robot Double Glass Making Machine For Insulating Glass

Brand Name : WGM

Model Number : WL2000-31/32

Certification : CE

Place of Origin : CHINA

MOQ : 1SET

Price : USD39000/SET

Payment Terms : L/C, T/T, Western Union

Supply Ability : 200SETS/YEAR

Delivery Time : 30DAYS

Packaging Details : PLYWOOD PALLET AND PLASTIC FILM

max glass size : 2500X2000MM

Colour : common colour is BLUE,can design as customer's demands

sealing speed : 5-30m/min

sealing depth : 2-15mm

Contact Now

Automatic Sealing Robot Double Glass Making Machine For Insulating Glass

Product Description

The Introduction of System

This system is a set of automatic sealing system for double glazing/triple glazing insulating glass

The system can be sealed for different size of the hollow glass processing. The system is shown in the figure below:

Function

Friendly man-machine interface is concise users will be more convenient to operate.

This system has the thickness detection device and depth detection device by the high resolution sensors.

Combined with automatically sealing function and adjusting the volume of the glue,it can greatly improve the efficiency of production.

This system is equipped with a clamping device, which can insure the glass to move more securely in the process of transmitting and gluing.

This system can be used in triple glazing glass. Firstly,it glues for the first space,when it finishes,the rubber head will adjust the angle for gluing the second space.

The V belt can adjust automatically according to the thickness of glass.

Rubber head pressure device can adjust glue head moving cylinder pressure through the precision of electric proportional valve to make the glue head attach the glass more smoothly

The structure of centering rubber head can adjust the rubber head according to the thickness of glass to ensure the effect of the gluing

The system has the "connection"system.The "connection"means that it can combine the production line with the sealing system to improve the production efficiency.

The cleaning function, When it is used for a long time or not used, the worker must clean the rubber tube(blunt glue) to avoid solidifying the rubber tube.When the worker adopts the cleaning function,the glue in the rubber tube will be discharged to avoid solidifying and protect rubber tube.

All components are high standard to be sure that the machine can be used stable for a long time.

The edge of glass is full without airline,and the corner is enriched without repairing it.

Max glass size	2500x2000mm
Min glass size	300x300mm
Glass thickness	3-12mm
Insulating glass thickness	12-56mm
Sealing speed	5-30m/min
Sealing width	6-24mm
Sealing depth	2-15mm
Conveyor speed	0-48m/min
Power supply	13kw
Air supply	0.5-0.8Mpa
Working height	520-580mm
Dimension	8500(L)x3200(W)x3400(H)mm

Product Details

Automatic Sealing Robot Double Glass Making Machine For Insulating Glass

Our Certifications

Automatic Sealing Robot Double Glass Making Machine For Insulating Glass

FAQ

1.Question:Are you a manufacturer?

Answer:

Yes,we are the professional insulating glass processing machines manufacturer, which has 16 years history since 2001.

2.Question: How about the service ?

Answer:

1).Reply it at once in WhatsAPP,if by email,it will be reply within 12 hours.

2).18 hours for after-sale serive

4).more than 15 years experience in this kind machine field

5).fluent english ,communication barrier free. Point-to-point service help you solve the problems timely.

3.Question:What's the guarantee ?

Answer:

1). Our guarantee for 12 months.

2). 18 hours' technical support by email, video or calling

3). English manual and video tutorial

4). 24 hours on line service each day, free professional technical support.

4. Q: Do you provide equipment operation training?

Answer:

A: Yes. We can will send one or two professional technicians (one is electrical engineer, one is mechanical engineer) to install and adjust the machines and help train the workers.

5.Question:Why your price isn't the lowest price compared with others company or factories ?

Answer:

1) We are a innovative enterprises. We have a a professional and experienced technical elite team. Every year we will apply for innovation patents for our insulating glass machine, likes auto gas filiing machine, auto loading machine and etc.

2)Compared with the same level brand, we have the same functions and components, but our price is the most competitive. At the same time, our after sales service is satisfactory. We have a good reputation in our customers.
